3M TEXTOOL BGA OPEN-TOP SOCKETS,1.27 MM
? ?
OPEN-TOP DESIGN
? ACCOMMODATES A WIDE RANGE OF PACKAGE THICKNESSES
WITHOUT REQUIRING SOCKET ADAPTATIONS
? ALLOWS EXCELLENT AIR ?OW AROUND DEVICE
? INCLUDES A RETRACTABLE LOCATING GUIDE FOR EASY BOARD
MOUNTING, EVEN WITH HUNDREDS OF LEADS
VERTICAL ACTUATION
? COMPATIBLE WITH MOST ROBOTIC HANDLERS
? EASY MANUAL OPERATION
NORMALLY CLOSED CONTACT DESIGN
? DUAL BEAM CONTACT DELIVERS BALANCED, OPPOSING FORCES TO
SOLDER BALL WITH MINIMAL SHEAR STRESS
? CONTACT TIPS TOUCH BALL ABOVE ITS CENTER PLANE PRODUCING ONLY
SLIGHT INDENTATIONS AND NEGLIGIBLE BALL DEFORMATION
RETAINER CLIP FEATURE
3M TEXTOOL SOCKETS ARE DESIGNED TO FUNCTION PROPERLY WITHOUT THE USE OF RETAINER CLIPS. THE RETAINER CLIP FEATURE IS DESIRABLE
FOR HIGH VIBRATION/SHOCK APPLICATIONS AND WITH SMALL OR NON-SPHERICAL SOLDER BALLS. THE PURPOSE OF THE RETAINER CLIP FEATURE IS
TO RETAIN THE DUT IN THE SOCKET SHOULD THERE BE AN EVENT OR CONDITIONS LEADING TO DISLODGEMENT OF THE SOLDER BALLS FROM THE
SOCKET CONTACTS. RETAINER CLIPS ARE CUSTOM-DESIGNED BASED ON SPECI?C PACKAGE DIMENSIONS AND SHOULD ONLY BE CONSIDERED
FOR STABLE PRODUCTION APPLICATIONS WHERE PACKAGE DIMENSIONS ARE NOT EXPECTED TO VARY. IN CASES OF NON-SPHERICAL AND SMALL
SOLDER BALLS, 3M TECHNICAL SERVICE MAY REQUEST PACKAGE SAMPLES FOR ?T ANALYSIS.
3M TEXTOOL BGA OPEN-TOP SOCKETS, 1.27 MM
MAXIMUM
MAXIMUM
MAXIMUM
TYPE
II
III
BODY SIZE (MM)
35 X 35
45 X 45
MATRIX
27 X 27
35 X 35
BALL COUNT
729
1225
STATUS
AVAILABLE
AVAILABLE
ORDERING INFORMATION
2 XXX-92 X X-XX-X X X X
PIN COUNT
PRODUCT SERIES NUMBER
MATERIAL TYPE
1 = PES/BECU/AU
SOLDER TAIL LENGTH
0 = 2.4 MM
PRODUCT PLATFORMS
2 = TYPE II
3 = TYPE III
PACKAGE SIZE / MATRIX VARIATION
(ASSIGNED BY 3M)
RETAINER
4 = WITHOUT (STANDARD)
5 = WITH
BOARD LOCATING POST
PRODUCT VARIATION 0 = WITHOUT
(ASSIGNED BY 3M) 1 = WITH (BOTH ALIGNMENT PLATE AND BASE)
2 = WITH (ALIGNMENT PLATE ONLY)
3 = WITH (BASE ONLY)
5
